Welcome to intelliDesign - our Switchboard panel design service, where safety and organisation come first. We specialise in creating high-quality panels featuring RCBOs and terminal rail enclosures, all built to meet strict electrical standards. Our designs utilise the internationally recognised DIN rail system, ensuring both efficiency and reliability. Trust us to solutions that prioritise safety and in every project.

All About IntelliDesign - Panel Designers

intelliDesign, a proud subsidiary of IntelliCasa Ltd, in innovative lighting design panels that enhance both functionality and aesthetics in any space. With a team of experts, intelliDesign focuses on delivering solutions tailored to meet the unique needs of their clients. Their commitment to quality and cutting-edge technology ensures that each panel not only meets industry but also elevates the overall ambiance of any environment. Trust us to provide panel deisngs that illuminate your spaces with safety and style.

Manufacturers we partner with

Our automation engineers are certified across a range of systems, including the following key partners:


Key Design Principles

​

  • Safety Standards: All designs must comply with relevant safety standards, such as IEC 61439 series, and local wiring regulations. Only qualified electricians should perform the installation and wiring.

  • Component Organisation: A logical and functional layout is essential for efficiency and maintenance.

  • Sufficient Space: The enclosure must be adequately sized to accommodate all components, allow for proper cable management, and prevent heat build-up.

  • Clear Labelling: Wires, terminals, and components must be clearly labelled for easy identification and troubleshooting.

​​

A standard panel layout includes the following elements, often mounted on DIN rails:

  • Main Switch/Isolator: An incomer switch to cut power to the entire switchboard.

  • RCBOs (Residual Current Breakers with Over-current protection): These devices combine the functions of an MCB (Miniature Circuit Breaker, for overload and short-circuit protection) and an RCCB (Residual Current Circuit Breaker, for earth leakage protection) into a single unit, protecting individual circuits.

  • DIN Rails: Standardised metal strips used for mounting circuit breakers, terminal blocks, relays, and other control devices.

  • Earth and Neutral Bars: Dedicated terminal bars or blocks for secure earthing and neutral connections.

  • Terminal Blocks: Used to connect and organise external wiring securely onto the DIN rail.

  • Cable Management: Integrated trunking or wireways help to route and separate high and low voltage cables neatly and safely.

  • Enclosure: A protective box (metal or plastic) that houses all components, with a hinged or removable cover and sometimes a lockable door. â€‹â€‹

Typical Layout Components

Wiring Considerations

​

  • RCBO Connections: The RCBO's "flying neutral lead" should connect directly to the neutral bar, while the circuit's neutral wire connects within the RCBO's terminal, preventing unwanted RCD tripping common in mixed RCD/MCB setups.

  • Busbars: Copper comb busbars can be used to link the live terminals of multiple RCBOs, providing an efficient and tidy power distribution solution.

  • Spare Capacity: It is good practice to include spare ways or poles in the initial design to allow for future circuit expansion.

  • Blanking Plates: Use proprietary pole fillers or blanking modules on any unused DIN rail space for safety and a professional finish.
